PRODUCT RANGE

Beverage Cans

KW141A

Automatic Axial Load – Dome Growth and Dome Buckle Gauge

TESTS

The world’s only dual station gauge with axial load, dome growth & dome buckle!

Tests any 2 standard beverage can diameters including 202, 204, 206 and 211 cans without changeover.

Tests any 2 standard beverage necks 200, 202 and 206 without changeover.

Tests standard beverage can heights from 250ml through 600ml without changeover.

FEATURES

Real time graphing of Axial Load/Distance and Dome Growth/Pressure.

Dual Dome Buckle/Growth Stations. Each station can be fitted with either 202, 204, 206 or 211 clamps.

Dual Axial Load Station. Each station can be fitted with 200,202 or 206 neck adapters.

Accept / reject lanes.

V2 Microprocessor Controller. No PC and no Microsoft Windows.

15” Colour LCD touch screen interface.

3 lane conveyor.

Ethernet Data Transfer.

USB port for program updates, settings backup and off line data storage.

Standard Colour: Blue Hammer tone Powder Coat.

INCLUDES

Operation manual including spare parts and safety test procedures

Power lead to suit region

Gauge Safety Test Report and record of safety feature testing.

Calibration ceertificate traceable to NATA/NIST

OPTIONAL EXTRAS

Dome Station Clamp Assembly
202, 204, 206 and 211 sizes available.

Axial Load Station Neck Adapter
200, 202 or 211 sizes available.

Digital Pressure Calibration Gauge
Allows periodic calibration of pressure measurement system.

Model: DRUCK DPI 705

  • Complete with carry case, tubing and
  • calibration connector
  • 35Bar Full Scale
  • Basic accuracy ±0.2% of FS
  • NATA Certified. (Internationally traceable)

Force Calibrator
Allows axial load station to be periodically calibrated.

Model No: FC070-250

  • Digital Display
  • Selectable units (Kg, N, Lb)
  • Special override feature to eliminate overload possibility.
  • Isolation rubber ensures stable settling of application force

KW141A Basic Spare Parts Kit
Kit includes-

  • 4 Dome Station Seal Kit. 6 off seals of each size.
  • 5 Pickup head O-Ring Kit.



http://www.youtube.com/watch?v=YPSGokobVhI
